When you calibrate, you optimize the quality of copied and scanned jobs. The press prints a calibration pattern for you to place on the document platen glass. The press then scans the calibration pattern, and automatically makes adjustments as required.

Note: This does not improve the image quality of print jobs, only jobs that are being copied and scanned.

1. Log in as the Administrator. See the Related Content for additional information.
2. Select the Machine Status button on the UI.
3. Select the Tools tab.
4. Select Setup & Calibration > Calibration.
5. Select either Copy Job 1 or Copy Job 2 for the Screen Type.
6. Select Paper Supply and choose the desired paper tray.

   Note: You should calibrate on your most frequently used paper.


7. Select Start. By default, the Target is set Copy Jobs Only, if it is not then Select Copy Jobs Only.
8. Select Start. The press prints a calibration chart and instructions display on the UI.
9. Collect the print and follow the directions on the UI to position the target onto the Document Glass.
   1. Place the chart face down with the two square Magenta patches against the left edge of the Document Glass.
   2. Place sheets of white paper over the chart.
10. Lower the Document Feeder Cover and select Start. The UI displays a Calibration in process message, and then displays a Calibration has been successfully completed message.
11. When the calibration is complete, touch Confirm.
12. Select Close. The main Tools tab screen displays.
13. Exit the Administrator mode
