Type
|
Color Digital Multifunction Imaging System
Letter: Up to 35/30 ppm
Legal: Up to 20/18 ppm
Ledger: Up to 20/18 ppm
|
|
Functions
|
Standard: Copy, Print (UFR II), Scan, Send, Store
Optional: Print (PCL, Adobe® PostScript® 3™), Fax (Up to 4 Lines)
|
|
Operation Panel
|
8.4" SVGA Full-Color TFT Screen
|
|
Image Server Memory
|
Standard: 2GB RAM
Maximum: 2.5GB RAM
|
|
Hard Disk Drive
|
Standard: 160GB
Maximum: 1TB
|
|
Mirroring Hard Disk Drive
|
Optional (160GB, 1TB), Method: RAID1
|
|
Network Interface Connection
|
Standard: 1000Base-T/100Base-TX/10Base-T
Optional: Wireless LAN (IEEE 802.1x via third-party adapter)
|
|
Other Interface
|
Standard: USB 2.0 (Host) x 2, USB 2.0 (Device)
Optional: Device Port [USB 2.0 (Host) x 2], Serial Interface, Copy Control Interface
|
|
Max Mailboxes Supported
|
100 User Inboxes, 1 Memory RX Inbox, 50 Confidential Fax InboxesApprox.
|
|
Max Pages Stored
|
6,000 Maximum Pages Stored
|
|
Advanced Box
|
|
|
Available Disk Space
|
15GB (Standard HDD)
Approx. 629GB (1TB HDD)
|
|
Common Protocol
|
SMB or WebDAV
|
|
Supported Client PC
|
Windows® (Windows 2000/XP/Windows Vista®)
|
|
Max. Number of Concurrent Connections
|
SMB: 32, WebDAV: 12 (Active Sessions)
|
|
Advanced Box Features
|
Disabling Advanced Box, Storage Filtering, Authentication for Advanced Box Log-in, Search Function, Sort Function, Printing a PDF File with a Password, imageWARE Secure Audit Manager Support
|
|
Memory Media
|
|
|
Standard
|
USB Memory
|
|
Optional
|
SD, SDHC, CompactFlash, Memory Stick, Microdrive
|
|
Scan Specifications
|
|
|
Network TWAIN Scan
|
Standard
|
|
Network Scan Utility
|
Color Network ScanGear
|
|
Standard Paper Capacity
|
Dual 550-sheet Paper Cassettes,
100-sheet Stack Bypass
|
|
Optional
|
Dual 550 Sheet Paper Cassettes,
2,700-sheet Paper Deck
|
|
Maximum Paper Capacity
|
5,000 Sheets
|
|
Output Paper Capacity
|
(20 lb. Bond): Standard: 250 Sheets (Inner Tray)
Maximum: 3,250 Sheets (w/Staple Finisher or Booklet Finisher)
|
|
Output Sizes
|
|
|
Cassette
|
12" x 18", 11" x 17", Legal, Letter, Letter-R, Statement-R, Executive, Custom Size (5-1/2" x 7-1/8" to 12" x 18")
|
|
Bypass
|
12" x 18", 11" x 17", Legal, Letter, Letter-R, Statement, Statement-R, Executive, Custom Size (3-7/8" x 5-1/2" to 12-5/8" x 18")
Paper Deck: Letter
|
|
Other Option
|
Envelope Feeder Attachment (COM10 No.10, Monarch, DL, ISO-C5) Tab Feeding Attachment Kit
|
|
Acceptable Paper Weights
|
|
|
Cassette
|
14 lb. Bond to 80 lb. Cover (52 to 220g/m2)
|
|
Bypass
|
14 lb. Bond to 140 lb. Index (52 to 256g/m2)
|
|
Duplexing
|
|
|
Paper Size
|
Standard Automatic Trayless Duplexing (Executive to 12" x 18")
|
|
Paper Weight
|
14 lb. Bond to 80 lb. Cover (52 to 220g/m2)
|
|
Special Media Support
|
Thin, Plain 1 [17 lb. Bond to 21 lb. Bond (64g/m2 to 81g/m2], Plain 2 [22 lb. Bond to 28 lb. Bond (82g/m2 to 105g/m2)], Recycled, Color, Pre-Punched, Bond, Heavy 1 [29 lb. Bond to 60 lb. Cover (106g/m2 to 163g/m2)], Heavy 2 [61 lb. Cover to 80 lb. Cover (164g/m2 to 220g/m2)], Heavy 3 [82 lb. Cover to 140 lb. Index (221g/m2 to 256g/m2)], Tracing, Coated, Labels, Transparency, Tab, Letterhead, and Envelopes
|
|
Warm Up Time
|
From Power On: 31 Seconds, From Sleep: 15 Seconds Quick Startup Mode: 7 Seconds***
|
|
Power Requirements
|
120V AC, 60Hz, 15A
|
|
Power Consumption
|
Maximum: 1.5kW
Sleep Mode: 0.8W
|
|
Plug
|
NEMA 5-15P
|
|
Dimension
|
37-3/8" x 24-3/8" x 28-1/8"
(950mm x 620mm x 715mm)
|
|
Installation Space
|
33-1/2" x 28-1/8" (850mm x 715mm)
|
|
Weight
|
Approx. 346 lb. (157kg)†
|
|
Image Reader
|
|
|
Scan Resolution
|
Up to 600 x 600 dpi
|
|
Acceptable Originals
|
(Glass): Sheet, Book, 3-Dimensional objects [up to 4.4 lb. (2kg)]
|
|
Maximum Original Size
|
Up to 11" x 17"
|
|
Basic Copy Features
|
First Copy Time: BW: 5.4 Seconds, Color: 8.1 Seconds
Multiple Copies: 1 to 999
Copy Exposure: Automatic or Manual (9 Levels)
Magnification: 25% - 400% (1% Increments)
Preset Reductions: 25%, 50%, 64%, 73%, 78%
Preset Enlargements: 121%, 129%, 200%, 400%
|
|
Security Features
|
|
|
Standard
|
Department ID Management, Single Sign On-H, Access Management System (Device and Function Level Log-in), Secured Print, Trusted Platform Module, User Access Control of Advanced Box, Mail Box Password Protection, IPV6, Restricting Features (Restricting the Send Function, Restricting New Addresses on Address Book), SSL Encrypted Communication, SNMPv1/v3, MAC/IP Address Port Filtering, SMTP Authentication, POP Authentication before SMTP, HDD Erase (Up to 3x), HDD Initialize (Up to 9x), HDD Lock, IPSec, Adobe LiveCycle Rights Management ES2.5 Integration
|
|
Optional
|
Removable HDD, HDD Encryption, HDD Mirroring, Encrypted Secure Print, Encrypted PDF, Document Scan Lock, Secure Watermark, IEEE 2600.1 Common Criteria Certification
|
|
Environmental Features
|
· EPEAT® Rated
· ENERGY STAR® Qualified
· RoHS Compliant
· Ecomark
· Blue Angel
· WEEE Directive
|
