Print head | On-demand Piezo head 16 printheads (4x4 lines in a staggered layout) |
|||||
Print resolution | 600, 1,200dpi | |||||
Ink | Type/Colour |
|
||||
Capacity | Supplied from 1-liter bottles for each color |
|||||
Maximum diagram dimensions (W×D) | 2,500×1,300 mm (98.4×51.2") | |||||
Media absorption | Blower adsorption type + foot switch | |||||
Number of absorption area partitions | 2 partitions (X-axis direction) | |||||
Curing device | LED-UV system | |||||
Media | Dimensions (W×D) | Up to 2,500×1,300 mm (98.4×51.2") | ||||
Height | Max. 60 mm | |||||
Weight | Less than 50 kg/m2 (110.2 lb./ft2), non concentrated load | |||||
Power supply | (Single phase, AC200-240V±10%, 50/60Hz±1Hz, 24 A) ×3 | |||||
Power consumption | INLET1 to 3 | Each INLET: Less than 4.8 kVA | |||||
Interface |
Ethernet 10GBASE-T |
|||||
Operational environment |
Temperature: 20 – 30 °C (68 – 86 °F) Accuracy maintained temperature : 20 – 25 °C (68 – 77 °F) Temperature gradient : Less than ± 10 °C/h (± 18 °F/h) |
|||||
Weight | Approx. 1,200 kg (2,645.5 lbs.) or less | |||||
Assembled Dimensions (W×D×H) | Approx. 5,300×2,850×1,700 mm (208.7×112.2×66.9") or less |
330% faster than the previous model (JFX500-2131) by installing significantly more printheads.
The great increase in productivity allows for quick delivery of large format prints.
Six colors, including Lc and Lm, are available for rich color expression.
There are a wide variety of UV ink types to choose from to suit your application.
Every ink has gained the “GREENGUARD Gold” certification by meeting VOC (Volatile organic compound) emissions requirements, the most stringent standard in the world, from UL, a U.S. third-party safety science organization, and is recognized for its environmental safety.
It is a new software used for operation in the touch screen monitor connected to the printer. All operations are visually organized by item and can be performed on the MPC screen, including setting print conditions, checking work/printer status and work history, and checking maintenance instructions.
One-touch instructions can be given for checking printer status, selecting jobs, etc.
The highly visible screen makes it easy to select conditions.
The table size of 2,500 × 1,300 mm nicely fits commonly used 4' × 8' media*.
The vacuum area to hold media is divided into two sections in the X direction of the table, and can be adjusted to the media size you use by opening/closing valves. Besides the operation panel, a foot switch can be used to turn the vacuum on and off.
*1,220mm×2,440mm
Direct printing on media as thick as 60 mm allows you to expand the range of materials.
You can also print on standard 50 mm thickness channel boards with aluminum composite board, PVC board, etc. laminated on the front and back (real 52-53 mm thickness)!
NCU (Nozzle Check Unit) detects the status of nozzles automatically. When the NCU detects a missing nozzle, it automatically performs cleaning. If cleaning does not solve the problem, NRS (Nozzle Recovery System) automatically replaces the defective nozzles with other nozzles, which enables users to continue their operation without waiting for service representative.
An ink circulation mechanism is provided in the ink tank and ink path. It circulates white ink periodically to prevent nozzle trouble due to deposited ink pigments and to stabilize printing performance.
In addition, MCT contributes to reduction of ink waste, thereby supporting environmentally and economically friendly applications.
Multi-layered gradation data can be created by “2.5D Texture Maker”, a function of the bundled RIP “RasterLink7”.
Smooth expression of bumpy textures can be achieved using multiple layers of UV ink. This allows you to create realistic and eye-catching graphics.
Printing together with high-concentration white ink as the base color on transparent or deep-color media makes full-color images more vivid.
Clear ink printing enhances decorative effects such as mat, gloss and texture.
It is an inkjet primer that improves the adhesion of materials such as resin, glass, metal and those surface-finished.
Expanding the range of material selection, high value added applications can be produced.
As the primer, PR-200 is applied simultaneously with color printing, the PR-200 applying only to the necessary part of material is possible, too.
Therefore the texture of the base material that was lost by conventional manual primer applying can be maintained.
