Brand New Mimaki Tx300P-1800 MKII 75.6" (Media) Hybrid Direct-to-Textile Inkjet Printer
Uniquely designed with versatility at its core, this printer enables both direct-to-textile and transfer printing. Combined with interchangeable print platen and three different dual ink combinations, it offers unrivalled flexibility within a single system. It affords all of the well-known benefits of digital print technology, including more cost-effective short runs and faster turnarounds. Such benefits are not attainable using analogue print methods, which are still prevalent in the modern textile printing industry; benefits that make this technology also ideal for sampling.
Digital textile printer for natural and synthetic fibres.
Mimaki TX300P-1800 direct to textile printer.
Mimaki’s has undisputed expertise in the digital textile sector. This is reflected in the innovative new Tx300P-1800 MKII. It has capability to print direct onto almost any type of natural or man-made fabric. Effortlessly combining quality and high speed, Tx300P-1800 MKII is ideally suited to applications such as fashion, furnishing, soft signage and exhibitions.
New printhead allows printing on various types of textile. When printing on raised fibre surface textiles, a high head gap setting is required to prevent contact between the printhead and the nap. In conventional models, these gap conditions reduce the accuracy of ink droplet placement. However, the new printhead ejects ink droplets at a high speed to maintain the straightness of the droplet direction, and accordingly accurate ink droplet placement is achieved. This enables high-quality printing on napped or thick textiles.
Choose 3 types of ink sets;
- Dye sublimation ink (transfer) + Textile pigment ink.
- Direct sublimation ink + Textile pigment ink.
- Dye sublimation ink (transfer) + Direct sublimation ink.
KEY FEATURES
- Maximum print speed of 68m2/hr
-
Switchable conveyance units supporting both paper and textile
Service engineers are no longer needed! You can easily replace platens manually. -
A variety of ink types capable of responding to print materials and hybrid ink supply system
One way and Hybrid are available. -
Ultimate design for usability ensuring high-quality production
New printhead, Reliable textile feeding mechanism -
Mimaki’s print technologies for achieving beautiful printing
– Mimaki Advanced Pass System 4 (MAPS4) reduces banding.
– Superior inkjet technology -
Uninterrupted printing solutions
– Nozzle Check Unit (NCU) automatically detects and cleans clogged nozzles.
– Nozzle Recovery System (NRS) uses only good nozzles as substitutes, when the clogged nozzles are not recovered after cleaning.
High-performance RIP software TxLink4 Lite*
The TxLink4 Lite offers simple RGB and CMYK colour replacement on raster and vector data, as well as the ability to produce different colour patterns. Moreover, various colour replacement functions can represent desired colors.
* TxLink4 Lite or RasterLink6Plus is bundled according to a user’ s choice.
Reliable textile feeding mechanism ensures stable printing
The tension applied to the textile during printing is varied according to changes in the outer diameter of the front and rear rolls. The Tx300P-1800 MKII monitors the applied tension and uniformly applies the optimum tension using the front and rear tension bars. High-quality printing is achieved during high-speed printing or even when using a large textile roll.
Mimaki Advanced Pass System 4
Advanced technology to prevent banding; swath boundaries are overprinted, whereas boundaries prone to banding are printed with fewer ink droplets.
Mimaki’s superior inkjet technology accurately places the ink droplets without losing their perfect circularity. This ensures that texts, lines, and edges are clearly and sharply printed.
Ultimate Advantage - Multi Printer playing two roles in one, available for both paper and textile
Tx300P-1800 from Mimaki splendidly reproduces rich color gradation and delicate sophisticated lines in textile printing. In Tx300P-1800 MkII, these capabilities have been taken to a new level, and long-awaited print on paper is now available with the "hybrid ink capability" which is another unique feature of this series.
As Dye sublimation ink (transfer) for printing on transfer paper has been added, you can now select from 3 types of ink sets; "Dye sublimation ink (transfer) + Textile pigment ink", "Direct sublimation ink + Textile pigment ink", "Dye sublimation ink (transfer) + Direct sublimation ink".*1,*2
Enabling print on paper will expand the possibilities of new materials and applications drastically.
*1: It is possible to load only one ink as with conventional models.
*2: The combination of “Dye sublimation ink (transfer) + Direct sublimation ink" is to be supported later.
Switchable conveyance units supporting both paper and textile
Service engineers are no longer needed! You can easily replace platens manually.
A variety of ink types capable of responding to print materials and hybrid ink supply system
One way and Hybrid are available.
Ultimate design for usability ensuring high-quality production
New printhead, Reliable textile feeding mechanism
Mimaki’s print technologies for achieving beautiful printing
- Mimaki Advanced Pass System 4 (MAPS4) reduces banding.
- Superior inkjet technology
Uninterrupted printing solutions
- Nozzle Check Unit (NCU) automatically detects and cleans clogged nozzles.
- Nozzle Recovery System (NRS) uses only good nozzles as substitutes, when the clogged nozzles are not recovered after cleaning.
- Mimaki Bulk Ink System 3 (MBIS3) for long-time continuous printing.
High-performance RIP software TxLink4 Lite*
The TxLink4 Lite offers simple RGB and CMYK color replacement on raster and vector data, as well as the ability to produce different color patterns. Moreover, various color replacement functions can represent desired colors.
* TxLink4 Lite or RasterLink6Plus is bundled according to a user' s choice.
The feature of digital textile printing
Substantial time savings and production time reduction from design to market enables fast response to clients orders.
No restriction in numbers of colors, smooth gradations and high quality printing.
Ecologically viable printing as only the required ink quantity is used for production. No excess water usage.
Production Example of Tx300P-1800 MkII
One way and Hybrid are available.
One way: One way ink set (1 type of ink is loaded)
Versatile use and ink type for direct printing in accordance with material and purpose.
Four colors for high productivity, six/seven/eight colors* for superior expressiveness.
* Only 8 color ink set is available for reactive dye Rc400/Rc500.
Rich variety of ink types in One way for any printing application
Mimaki offers five ink types -sublimation, dispersant, pigment, reactive, and acid- to meet various application needs.
Application: Apparel, Silk product, Fashion articles, Home fabrics, Car seat, Soft signage etc.
The Tx300P-1800 MkII optimizes the printing speed and quality to produce the desired print results. For this purpose, it provides a wide range of printing modes, from the draft printing mode (which operates at the maximum speed of 66 m2/h) to high-quality printing mode.
* DD400, TP400, Rc400/500, Ac400 inks cannot print in draft mode.
Hybrid: Hybrid ink set (Two types of inks can be loaded at the same time)
- Able to manage to use two types of ink properly in response to your needs.
- Available to print on both paper and textile with a single printer unit.
- Possible to create printed fabric simply with your existing processing equipment only such as heat press etc.
You can easily replace platens to suit the media type (textile or paper).
Also high-quality printing can be stably achieved by changing the conveyance route for textile and paper.
Versatile ink combination in Hybrid
Mimaki offers three ink combination to meet various application and media.
Application: Sports apparel, Fashion apparel, Wall paper, Poster, Soft signage etc.
Print speed (Hybrid ink set)
Ultimate design for usability ensuring high-quality production
While printing on raised fiber surface textiles, a high head gap setting is required to prevent contact between the printhead and the nap. In conventional models, such gap conditions reduce the accuracy of ink droplet placement. However, the new printhead ejects ink droplets at a high speed to maintain the straightness of the droplet direction, and accordingly accurate ink droplet placement is achieved. This enables high-quality printing on napped or thick textiles.
Reliable textile feeding mechanism ensures stable printing
Stable textile feeding and transportation are crucial for direct textile printing. The tension applied to the textile during printing is varied according to changes in the outer diameter of the front and rear rolls. The Tx300P-1800 MKII monitors the applied tension and uniformly applies the optimum tension using the front and rear tension bars. Thus, high-quality printing is achieved during high-speed printing or even when using a large textile roll.
Mimaki’s unique anti-banding technique MAPS4 is an advanced version of MAPS3. To prevent banding, swath boundaries are overprinted, whereas boundaries prone to banding are printed with fewer ink droplets.
Superior inkjet technology
Mimaki’s superior inkjet technology accurately places the ink droplets without losing their perfect circularity. This ensures that texts, lines, and edges are clearly and sharply printed.
Continuous operation support pack minimizes the downtime
The Nozzle Check Unit (NCU) detects nonfunctioning nozzles and automatically cleans them. If the nozzles fail to operate after cleaning, defective nozzles are replaced by non-defective ones until a technician arrives, and printing is continued. This feature enables uninterrupted print operations and continuous productivity.
Specifications
|
Model |
TX300P-1800 MkII |
|
|
Print Head |
On-demand piezo head (4 printhead in-line)(2 staggered printheads) |
|
|
Resolution (Depends on ink type) |
360 dpi, 540 dpi, 720 dpi, 1,080 dpi, 1,440 dpi |
|
|
Ink |
Type/ Color |
4/6/7/8c (*) |
|
Direct sublimation |
Sb420 (Bl, M, Y, K, Lbl, Lm) |
|
|
Disperse Dye |
DD400 (C, M, Y, K, R, Violet, Pink, Gray) |
|
|
Textile Pigment |
TP400 (C, M, Y, K, R, Bl, Lk) |
|
|
Reactive Dye |
Rc400/500 (C, M, Y, K, Lk, R, Bl, Or) |
|
|
Acid Dye |
Ac400 (C, M, Y, K, Lk, R, Bl, Or) |
|
|
Dye Sublimation (transfer) |
Sb411 (Bl, M, Y, K) |
|
|
Package Size |
2L Ink pack |
|
|
Media thickness |
1.0 mm or less |
|
|
Media roll weight |
40 kg or less |
|
|
Media type |
Natural fiber (Cotton, Silk, Hemp), Chemical fiber (Polyester, Nylon) *Excluding elastic media Paper |
|
|
Certifications |
VCCI class A, FCC class A, ETL UL 60950-1 ETL, ENERGY STAR, RCM, EAC,CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH |
|
|
Interface |
USB 2.0 Hi-speed / Ethernet 1000BASE-T |
|
|
Power |
Single-phase AC100 to 120V / AC200 to 240V 50/60Hz ± 1Hz |
|
|
Power Consumption |
(AC100V) 1,440W×1, (AC200V) 1,920W×1 |
|
|
Operation Environment |
Temperature: 20 – 30 degC, Humidity : 35 – 65% Rh (Non-condensation) |
|
|
Outer sizes (WxDxH) |
3,200 × 965 × 1,857 mm (126.0 × 38.0 × 73.2 in) |
|
|
Weight |
260 kg (573.2 lb) |
|
