| Processor | AMD Phenom™ II,Athlon™ II processor, Socket AM3 |
| Chipset | AMD® 770 + SB710 |
| Front Side Bus | 5.2 GT/s HyperTransport |
| Memory | Dual channel DDR3 1600(oc)/1333/1066 x 4 DIMMs, Max. 16GB |
| VGA on Die | Discreted |
| Expansion Slots | 1* PCIe 2.0 x16, 2* PCIe 2.0 x1, 3* PCI |
| IDE | ATA 133 * 1 |
| Serial ATA(SATA)/RAID | SATAII * 6 w / RAID 0, 1, 10 |
| Audio | 5.1 channel HD Audio |
| LAN | Gigabit LAN |
| IEEE1394 | N/A |
| Back Panel I/O Ports | 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x Series port 1 x Audio jack supports 3 jacks 6 x USB 2.0 ports 1 x RJ45 LAN jack |
| Internal I/O Connectors | 1 x ATX 24-pin power connector 1 x 4-pin ATX 12V power connector 2 x 4-pin CPU/System Fan connectors 1 x 3-pin NB Fan connector 1 x Front Audio header 1 x Front Panel header 1 x Buzzer 3 x USB 2.0 connectors support additional 6 ports 6 x SATAII connectors 1 x ATA133 IDE connector 1 x Intrusion Alarm header 1 x CD-in connector |
| BIOS Features | 8Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI |
| Support CD | rivers, DirectX10, Adobe Reader, SuperUtilities, Norton Internet Security |
| Standards/Manageability | PCI 2.3, USB2.0, DMI 2.5 |
| Special Features | |
| Form Factor | ATX ( 12.0" x 8.6") |
