Running at a maximum speed of 20 feet per minute with 4" heat rollers, the Spire III 44T machines is fast and retain heat better for longer runs. Even beginners will find the Spire III easy-to-use with a user-friendly control panel and auto grip, easy-load supply shafts for no-hassle film loading. Designed with an eye for increasing versatility, a 2" mounting gap allows for mounting of thicker substrates while optional unwinds and rewinds and roll-to-roll capabilities can be easily added later.
Simple, intuitive control panel with LED pressure readout Deep feed table makes feeding larger sheets effortless Hand crank for opening and closing rollers provides an infinite choice of settings 20 feet per minute laminating capability Foot pedal for hands-free operation Up to 44" wide laminating and mounting capabilities Independently controlled upper and lower heat rollers allow for running multiple thermal film gauges and PSA films concurrentlyProduct Specifications
-
Laminator Type - Wide Format
-
Dimensions - 61.5" X 31.5" X 55.9"
-
Core Diameter - 3"
-
Laminating Speed - 20' per minute
-
Maximum Document Width - 44"
-
Film Type - Thermal and Pressure Sensitive 3" Core Media and Films
-
Roll Width - 44"
-
Accessories Included - No
-
Cold Lamination - Yes
-
Thermal Lamination - Yes
-
Number of Rollers - 2 nip rollers, 2 pull rollers
-
Temperature Control - Yes
-
Net Weight - 691 lbs
-
Dated_Indicator - Undated
-
Material - Steel
